Rack And Pinion Type Mast Climbing Elevator SC300, SC300/300 60M/Min Speed

  • 1
  • 2

Brand Name : KANGBO

Model Number : Rack and pinion type elevator SC300BG, SC300/300BG

Certification : TUV, CCC

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiate

Payment Terms : T/T, L/C

Supply Ability : 150 sets per month

Delivery Time : 25-30 days

Packaging Details : Export package

name : Construction Site Rack Pinion Elevator

Application : Vertical transportation at construction site

Design : According to European Regulations and Modular

Material : Q355B steel

Production : As per EN 12159:2012, EN 60204-1:2006/A1:2009

Color : Yellow

Contact Now

Rack And Pinion Type Mast Climbing Elevator SC300, SC300/300 60M/Min Speed

It is the truly modular rack and pinion hoist design, so the elevator drive devices and cars are generic and interchangeable.
Multiple choice of construction lifts car doors or ramps is available.
The modular and standardizing system makes the Kangbo rack and pinion elevators be flexible, efficient, low ownership cost, making them the best choice for both construction and rental companies.

Main structure frame are made of 16Mn and Q355 high strength cold roll steel plate, cut by laser, process by CNC machines in tool fixtures, welded by robots.

Technical Data

Item & Article No. SC300BG; SC300/300BG
Payload Capacity 3,000 KG per Cage
Lifting Speed 0–60 m/min.
Max. Lifting Height 450m
Cage Size (internal) 3.2(Length)*1.5(Width)*2.35(Height) Meter per Cage
Cage Doors Flap type discharge door is available
Motor Control FC (Frequency Control)
Engine Power 3x23 KW per Cage
Gearbox Helical Gearbox
Safety Device Type Centrifugal Brake
Power Supply Range 380–500 V, 50 or 60 Hz, 3 Phase
Type of Mast Square Column 650*650 mm with Bolted Rack
Length Mast Section 1.508 m
Rack Module 8

Rack And Pinion Type Mast Climbing Elevator SC300, SC300/300 60M/Min Speed
